V5 AQUARIUS

FEATURES
Suitable for all audio or home theater systems
RFI reduction 65dB
6 optimised power cleaning circuits to effectively remove Common and Differential Mode mains noise
4 independent outlets for source components (6A)
2 independent high current outlets for power amps, active subwoofers, active loudspeakers, TVs etc. (16A)
Easy reset thermomagnetic fusing system
81’000A instantaneous protection, 40’000A continuous
Fully star-earthed network
Solid core Ohno Continuous Cast copper silver-plated internal wiring with FEP virtual air dielectric
SYSTEM LINK outlet for extending the outlets and maintaining a starred earth reference
Supplied with IsoTek EVO3 PREMIER POWER CABLE (1.5m)
Provides up to 3’680 watts (16A/230V) or 1’840 watts (16A/115V) of clean power, ensuring optimal energy delivery for your equipment
UK, EU, US, AU & CH outlets available

The original Aquarius was one of the most cost-effective power cleaning upgrades money could buy. The new V5 model takes the Aquarius concept to a higher level. There is more instant on tap power due to an increased 35% circuit board copper loading, direct current resistance is at least 25% improved moving closer to the ideal of zero Ohms. Protection is also raised to 81’000A instantaneous. This six-way mains power-cleaning unit resets the market standard. Two high-current outlets are provided for amplifiers, subwoofers and so on, with four medium-current sockets for other components. Each outlet of Aquarius has its own dedicated power-cleaning network, thus six power cleaners in one box!

IsoTek’s iconic Aquarius power cleaning system has been dramatically improved and boldly restyled. The V5 model is not only state of the art in its visual design, appearing hewn from a single block of aluminum but harness the latest technical innovations from a leading brand in the specialist field of power systems for audio and AV.

These technological improvements result in the V5 Aquarius delivering absolute power, unrestricted current delivery within what the power company can supply, and regulations allow.





The V5 design features two thermo magnetic fuses, one rated at 16A for the two high current power output sockets, delivering 3’680W at 230V or 1’840W at 115V. The second rated at 6A for the four remaining medium current output sockets, delivering 1’380W at 230V or 690W at 115V, these are dedicated for source components and feature IsoTek’s unique Adaptive Gating © technology. This autosenses the connected load and gives the ideal optimal clean power based upon power draw.

The internal wiring of IsoTek products synergizes with the range of IsoTek power cables. One critical but overlooked area, is maintaining commonality of design and material properties through an audio wiring loom, be it signal carrying cables or your power cable network.
